A Comparison of four routinely used Vitamin D automated immunoassays and an evaluation of clinical impact of arbitrary cut-off levels

Comparison of four Vitamin D immunoassays

  • Pavel Broz Institute of Clinical Biochemistry and Hematology, University Hospital Pilsen, Czech Republic
  • Jindra Windrichova Department of Immunochemistry Diagnostics, University Hospital Pilsen, Czech Republic
  • Radka Fuchsova Department of Immunochemistry Diagnostics, University Hospital Pilsen, Czech Republic
  • Ondrej Topolcan Department of Immunochemistry Diagnostics, University Hospital Pilsen, Czech Republic
  • Ladislav Pecen Department of Immunochemistry Diagnostics, University Hospital Pilsen, Czech Republic
  • Otto Mayer Second Internal Clinic, University Hospital Pilsen, Czech Republic
  • Radek Kucera Department of Immunochemistry Diagnostics, University Hospital Pilsen, Czech Republic
Keywords: Vit25OHD, Vitamin D, Unicel, Architect, Cobas, Liaison, method comparison


Aim: To compare four automated immunoassays for the measurement of vit25OHD and to assess the impact on the results obtained from a healthy population.

Methods: We analysed 100 serum samples on Unicel DxI 800 (Beckman Coulter), Architect i1000 (Abbott), Cobas e411 (Roche) and Liaison XL (DiaSorin). A Wilcoxon signed-rank test was used to compare the different methods’ values and method comparison was further performed using Spearman’s rank correlation, as well as linear and Passing-Bablok regression.  In order to clinically categorise the obtained values, results were categorised into the following groups: 0–25 nmol/l, 25–50 nmol/l, 50–75 nmol/l and above 75 nmol/l and compared. The percentage of samples below 75 nmol/l and below 50 nmol/l was then calculated for every method.
Results: According to paired comparisons, each method differs from others (P<0.0001) except Cobas vs. Architect, which do not show a statistically significant difference (P=0.39). The strongest correlation was found between Liaison and Architect (r=0.94, P<0.0001). The percentage of samples below the reference value of 75 nmol/l were: 70% (Abbott), 92% (Liaison), 71% (Cobas) and 89% (Unicel). The percentage of samples below the value of 50 nmol/l were: 17% (Abbott), 55% (Liaison), 28% (Cobas) and 47% (Unicel).
The observed differences stem from the use of different analytical systems for vit25OHD concentration analysis and can result in different clinical outcomes. The reference ranges should be established for each assay in accordance with data provided by the manufacturer or in the laboratory, in accordance with proper standardisation.


1. Adams JS and Hewison M. Update in Vitamin D. J Clin Endocrinol Metab. 2010 Feb;95(2):471–8.
2. Herrmann M. The measurement of 25-hydroxy vitamin D – an analytical challenge. Clinical Chemistry and Laboratory Medicine (CCLM). 2012 Nov 1;50(11):1873–5.
3. Ferrari D, Lombardi G, Banfi G. Concerning the vitamin D reference range: pre-analytical and analytical variability of vitamin D measurement. Biochem Med (Zagreb) [Internet]. 2017 Oct 15 [cited 2020 Apr 15];27(3). Available from: https://www.ncbi.nlm.nih.gov/pmc/articles/PMC5575654/
4. Wallace AM, Gibson S, de la Hunty A, Lamberg-Allardt C, Ashwell M. Measurement of 25-hydroxyvitamin D in the clinical laboratory: Current procedures, performance characteristics and limitations. Steroids. 2010 Jul 1;75(7):477–88.
5. Cashman KD, Dowling KG, Škrabáková Z, Gonzalez-Gross M, Valtueña J, De Henauw S, et al. Vitamin D deficiency in Europe: pandemic? Am J Clin Nutr. 2016 Apr;103(4):1033–44.
6. Lai JK, Lucas RM, Banks E, Ponsonby AL. Ausimmune Investigator Group. Variability in vitamin D assays impairs clinical assessment of vitamin D status. Intern Med J 2012; 42:43-50.
7. Nowson CA, McGrath JJ, Ebeling PR, Haikerwal A, Daly RM, Sanders KM, et al. Vitamin D and health in adults in Australia and New Zealand: a position statement. Medical Journal of Australia. 2012;196(11):686–7.
8. Vuistiner P, Rousson V, Henry H, Lescuyer P, Boulat O, Gaspoz J-M, et al. A Population-Based Model to Consider the Effect of Seasonal Variation on Serum 25(OH)D and Vitamin D Status. Biomed Res Int [Internet]. 2015 [cited 2020 Apr 16];2015. Available from: https://www.ncbi.nlm.nih.gov/pmc/articles/PMC4569755/
9. Ricos C, Alvarez V, Cava F et al. Current databases on biological variation: pros, cons and progress. Scand J Clin Lab Invest 1999; 59:491-500.
10. European Federation of Clinical Chemistry and Laboratory Medicine , EFLM Biological Variation Database, https://biologicalvariation.eu/, accessed on 23rdJuly 2019.
11. Viljoen A, Singh DK, Farrington K, Twomey PJ. Analytical quality goals for 25‐vitamin D based on biological variation. J Clin Lab Anal. 2011 Mar 15;25(2):130–3.
12. Sempos CT, Heijboer AC, Bikle DD, Bollerslev J, Bouillon R, Brannon PM, et al. Vitamin D assays and the definition of hypovitaminosis D: results from the First International Conference on Controversies in Vitamin D. Br J Clin Pharmacol. 2018 Oct;84(10):2194–207.
13. Stöckl D, Sluss PM, Thienpont LM. Specifications for trueness and precision of a reference measurement system for serum/plasma 25-hydroxyvitamin D analysis. Clinica Chimica Acta. 2009 Oct 1;408(1):8–13.
14. Ozcan N, Ucar F, Arzuhal AE, Bulut E, Ozturk A, Taslipinar Yavuz M, et al. Evaluation of the analytical performance of Unicel DXI 800 for the Total 25 (OH) Vitamin D measurements. Clinical Biochemistry. 2016 Apr 1;49(6):486–91.
15. Sempos CT, Betz JM, Camara JE, Carter GD, Cavalier E, Clarke MW, et al. General Steps to Standardize the Laboratory Measurement of Serum Total 25-Hydroxyvitamin D. J AOAC Int. 2017 Sep 1;100(5):1230–3.
16. Durazo-Arvizu RA, Tian L, Brooks SPJ, Sarafin K, Cashman KD, Kiely M, et al. The Vitamin D Standardization Program (VDSP) Manual for Retrospective Laboratory Standardization of Serum 25-Hydroxyvitamin D Data. J AOAC Int. 2017 Sep 1;100(5):1234–43.
17. Carter GD, Berry J, Durazo-Arvizu R, Gunter E, Jones G, Jones J, et al. Quality assessment of vitamin D metabolite assays used by clinical and research laboratories. The Journal of Steroid Biochemistry and Molecular Biology. 2017 Oct 1;173:100–4.
18. Carter G, Walker E. Deqas review 2016/2017. 2017:1-23.
19. Heijboer AC, Blankenstein MA, Kema IP, Buijs MM. Accuracy of 6 routine 25-hydroxyvitamin D assays: influence of vitamin D binding protein concentration. Clin Chem. 2012 Mar;58(3):543–8.
20. Carter GD, Phinney KW. Assessing Vitamin D Status: Time for a Rethink? Clin Chem. 2014 Jun 1;60(6):809–11.
21. Cavalier E, Lukas P, Crine Y, Peeters S, Carlisi A, Le Goff C, et al. Evaluation of automated immunoassays for 25(OH)-vitamin D determination in different critical populations before and after standardization of the assays. Clinica Chimica Acta. 2014 Apr 20;431:60–5.
22. Binkley N, Dawson-Hughes B, Durazo-Arvizu R, Thamm M, Tian L, Merkel JM, et al. Vitamin D measurement standardization: The way out of the chaos. The Journal of Steroid Biochemistry and Molecular Biology. 2017 Oct 1;173:117–21.
Original paper
