Towards retardation of slag corrosion on the lightweight alumina refractory with static magnetic field facing green metallurgy

  • Ao Huang Wuhan University of Science and Technology Northeastern University
  • Pengfei Lian Wuhan University of Science and Technology
  • Lvping Fu Wuhan University of Science and Technology
  • Huazhi Gu Wuhan University of Science and Technology
  • Yongshun Zou Wuhan University of Science and Technology

Abstract


Electromagnetic field is widely found and used in metallurgy and other high temperature processes, and affects the behavior of melts. The lightweight alumina based carbon free refractory is of importance for energy-saving, consumption reducing and high quality steel production, and the slag corrosion resistance is significantly concerning its service life. Does electromagnetic field control the slag corrosion behavior on the lightweight alumina refractory? In this paper, a multi-field coupled model was established to describe the slag corrosion process in an electromagnetic field. The mathematical modeling in combination of experiments was applied to clarify slag corrosion behavior of lightweight alumina refractory in static magnetic field. The simulation results agree well with that of the experiments, which mean the above model is promising for slag corrosion modeling. The results show that a static magnetic field could change properties of the molten slag and enhance the slag corrosion resistance by inhibiting slag penetration and promoting formation of a directional isolation layer, and be beneficial to clean steel production with high quality.

Author Biographies

Ao Huang, Wuhan University of Science and Technology Northeastern University
The State Key Laboratory of Refractories and Metallurgy, China
Pengfei Lian, Wuhan University of Science and Technology
The State Key Laboratory of Refractories and Metallurgy
Lvping Fu, Wuhan University of Science and Technology
The State Key Laboratory of Refractories and Metallurgy
Huazhi Gu, Wuhan University of Science and Technology
The State Key Laboratory of Refractories and Metallurgy
Yongshun Zou, Wuhan University of Science and Technology
The State Key Laboratory of Refractories and Metallurgy

References

Z. Cao, J. Fei, X. Zhang, H. Hao, J. Jin, Materials Science & Engineering A, 327(2) (2002) 133-137. https://doi.org/10.1016/S0921-5093(01)01673-2

Z. Zhang, H. Jia, X. Zhang, K. Deng, Z. Ren, Z. Lei, Advanced Materials Research, 402 (2012) 46-50. DOI:10.4028/www.scientific.net/AMR.402.46

M. C. Mantovani, L. R. Moraes, R. L. D. Silva, E. F. Cabral, E. A. Possente, C. A. Barbosa,B. P. Ramos, Ironmaking & Steelmaking, 40(5) (2013) 319-325. http://dx.doi.org/10.1179/1743281212Y.0000000035

Z. Deng, M. Zhu, S. Du, Metallurgical & Materials Transactions B, 47(5) (2016) 1-10. https://doi.org/10.1007/s11663-016-0746-2

H. Sarpoolaky, S. Zhang, B. B. Argent, W. E. Lee, Journal of the American Ceramic Society, 84(2) (2010) 426-434. DOI: 10.1111/j.1151-2916.2001.tb00672.x

H. Sarpoolaky, S. Zhang, W. E. Lee, Journal of the European Ceramic Society, 23(2) (2003) 293-300. https://doi.org/10.1016/S0955-2219(02)00170-X

S. Yilmaz, Ironmaking & Steelmaking, 33(2) (2006) 151-156. http://dx.doi.org/10.1179/174328106X80109

M. Jiang, Z. Chen, Journal of the Chinese Ceramic Society, 18(3) (1990) 256-261. DOI: 10.14062/j.issn. 0454-5648.1990.03.009

Z. Chen, Journal of the Chinese Ceramic Society,11(4) (1983) 498-507. DOI: 10.14062/j.issn.0454-5648.1983.04.015

J. L. Bates, Journal of the American Ceramic Society. 70(3) (1987) C-55-C-57. DOI: 10.1111/j.1151-2916.1987.tb04965.x

S. Zhang, R. H. Reza, S. Hossain, L. W. Edward, Journal of the American Ceramic Society. 83(4) (2000) 897-903. DOI: 10.1111/j.1151-2916.2000.tb01291.x

J. Pötschke, C. Brüggmann, Steel Research International, 83(7) (2012) 637-644. DOI: 10.1002/srin.201100294

A. Huang, H. Gu, Y. Zou, L. Fu, P. Lian, L. Jin, Ceramic Transactions. 256 (2016) 101-111. DOI: 10.1002/9781119234593.ch11

L. Fu, H. Gu, A. Huang, M. Zhang, Z. Li, Journal of the American Ceramic Society, 98(5) (2015) 1658-1663. DOI: 10.1111/jace.13487

L. Fu, A. Huang, P. Lian, H. Gu, Corrosion Science, 120C (2017) 211-218. DOI: 10.1016/j.corsci.2017.01.018

X. Li, B. Zhu, T. Wang, Ceramics International, 38(3) (2012) 2105-2109. DOI: 10.1016/j.ceramint.2011.10.049

X. Li, B. Zhu, T. Wang, Ceramics International, 38(4) (2012) 2883-2887. DOI: 10.1016/j.ceramint.2011.11.061

K. Okazawa, M. Yamane, Y. Fukuda, Tetsu- to- Hagane. 89(6) (2009) 629-636. DOI: 10.2355/tetsutohagane1955.89.6_629

X. Wang, L. Zhu, Y. Zhang, Z. Li, The 2nd National Conference on Electromagnetic Metallurgy and Strong Magnetic Field Materials, 20-23 August, Baotou, China, 2014, p. 21-23.

J. Pötschke, 51st International Colloquium on Refractories for Metallurgy, 15-16 October, Aachen, Germany, 2008, p. 144-146.

L. B. Khoroshavin, V. B. Shcherbatskii, Refractories & Industrial Ceramics, 46(5) (2005) 344-351. https://doi.org/10.1007/s11148-006-0010-4

C. G. Aneziris, M. Hampel, International Journal of Applied Ceramic Technology, 5(5) (2008) 469-479. DOI: 10.1111/j.1744-7402.2008.02223.x

J. Berjonneau, P. Prigent, J. Poirier, Ceramics International, 35(2) (2009) 623-635. https://doi.org/10.1016/j.ceramint.2008.04.002

A. P. Luz, A. G. T. Martinez, M. A. L. Braulio, V. C. Pandolfelli, Ceramics International, 37(4) (2011) 1191-1201. https://doi.org/10.1016/j.ceramint.2010.11.043

H. Harmuth, S. Vollmann, Interceram International Ceramic Review, (2) (2011) 88-90.

K. Mukai, Z. Tao, K. Goto, Z. Li, T. Takashima, Scandinavian Journal of Metallurgy, 31(1) (2010) 68-78. DOI: 10.1034/j.1600-0692.2002.310109.x

A. Huang, H. Gu, Y. Zou, Proceedings of the Unified International Technical Conference on Refractories 2013, 10-13 September, Vancouver, Canada, 2013, p. 863-868.

J. Choi, H. Lee, Transactions of the Iron & Steel Institute of Japan, 43(9) (2003) 1348-1355. DOI: 10.2355/isijinternational.43.1348

Y. Zou, H. Gu, A. Huang, M. Zhang, C. Ji, Ceramics International, 40(5) (2014) 7023-7028. https://doi.org/10.1016/j.ceramint.2013.12.030

C. W. Bale, E. Bélisle, P. Chartrand, S. A. Decterov, G. Eriksson, A. E. Gheribi, et al. Calphad, 54 (2016) 35-53. https://doi.org/10.1016/j.calphad.2016.05.002

Y. Liang, A. Huang, X. Zhu, H. Gu, L. Fu, Ceramics International, 41(6) (2015) 8149-8154. https://doi.org/10.1016/j.ceramint.2015.03.026

G. Zhang, B. Yan, K. Chou, F. Li, Metallurgical & Materials Transactions B, 42(2) (2011) 261-264. https://doi.org/10.1007/s11663-011-9484-7

N. Li, H. Gu, H. Zhao, Metallurgical Industry Press, Beijing, 2010, p. 50-60.

Published
2018/10/17
How to Cite
Huang, A., Lian, P., Fu, L., Gu, H., & Zou, Y. (2018). Towards retardation of slag corrosion on the lightweight alumina refractory with static magnetic field facing green metallurgy. Journal of Mining and Metallurgy, Section B: Metallurgy, 54(2), 143. Retrieved from https://aseestant.ceon.rs/index.php/jmm/article/view/15339
Issue
Vol. 54 No. 2 (2018)
